รายละเอียดสินค้า:
|
| Element detection range: | (Mg) and uranium (U) with atomic number of 12-92 | Analytical methods: | Direct reading analysis method+basic parameter method（FP） |
|---|---|---|---|
| Front end testing window: | *≤ 9mm * 5mm "waist" shaped window | Data transmission method: | 3G/4G, wired connection, WiFi, Blue tooth |
| Operating environment temperature and humidity: | humidity≤90% -20℃ - +60℃ | ||
| เน้น: | portable alloy composition spectrometer,chemical analysis spectrometer for alloys,non-destructive alloy testing equipment |
||
| Attribute | Value |
|---|---|
| Element detection range | (Mg) and uranium (U) with atomic number of 12-92 |
| Analytical methods | Direct reading analysis method+basic parameter method（FP） |
| Front end testing window | *≤ 9mm * 5mm "waist" shaped window |
| Data transmission method | 3G/4G, wired connection, WiFi, Blue tooth |
| Operating environment temperature and humidity | humidity≤90% -20℃ - +60℃ |
| Parameter | Specification |
|---|---|
| Detector | High performance silicon drift SDD detection module |
| Excitation source | 45KV/200uA Silver Target End Window Integrated Micro X-ray Tube and High Voltage Source |
| Element detection range | Elements between magnesium (Mg) and uranium (U) with atomic number of 12-92 |
| Detection object | Solid |
| Weight | ≤1.75KG (Including battery) |
| Power supply | Rechargeable lithium battery, standard configuration 6800mAh, voltage: 7.2V; Sustainable work for up to 12 hours |
| Safety | Instrument side measurement value ≤ 0.2 μSv/h (after deducting background) |
On-site analysis, testing, and sorting of waste metals and diverse alloy types for quick and reliable transaction judgments.
Alloy material identification (PMI) for industries including petrochemical, power plants, military, ensuring safety and compliance with international standards.
Essential for quality control in metal processing and manufacturing industries to prevent material mix-ups and ensure product quality.
Testing without damaging the object's performance or internal organization, with remote control capabilities through software.
