รายละเอียดสินค้า:
|
| Working distance: | 115mm | Changing times than: | 6.3:1. |
|---|---|---|---|
| Changing times objective: | 0.8~5X(total amplification 8~50X) (optional up to 4 ~ 100X) | Sight glass tube: | Tritocular lens with an inclination of 45° |
| Visibility adjustable eyepiece: | Wide field flat field eyepiece EW10X / / Φ 22 | ||
| เน้น: | digital stereoscopic microscope with 3MP camera,stereoscopic microscope for non-destructive testing,3MP camera microscope with warranty |
||
HSM-645S High Resolution Numerical Digital Camera Stereoscopic Microscope
System description
Specifications and parameters
| project | parameter | HSM-645S |
| Sight glass tube | Binocular lens with an inclination of 45° | |
| Tritocular lens with an inclination of 45° | ● | |
| Digital volumetric lens body, Angle of 45° | ||
| Visibility adjustable eyepiece | Wide field flat field eyepiece EW10X / / Φ 22 | ● |
| WF15X / Φ 16 | ○ | |
| WF20X / Φ 12 | ○ | |
| WF30X | ○ | |
| Changing times objective | 0.8~5X(total amplification 8~50X) (optional up to 4 ~ 100X) | ● |
| Changing times than | 6.3:1. | ● |
| Working distance | 115mm | ● |
| pd | 52-75mm | ● |
| The auxiliary lens | 0.5 x | ○ |
| 0.7 x | ○ | |
| 2 x | ○ | |
| The loading platform is inserted into the circular plate | Transparent glass plate 140mm in diameter | ● |
| Black and white board | ○ | |
| Lighting system | No light | ○ |
| Reflected light 100V-240V/LED | ● | |
| Transmitted light lighting 100V-240V/LED | ● |
● standard configuration, ○ optional configuration
options
| A. Computers and printers | B. Metallographic Image analysis and measurement software (Image-3000) |
Product features:
